T710 Double-Axle Agricultural Trailer - METAL-FACH Sp. z o.o.


T710 Double-Axle Agricultural Trailer

The T710 double-axle trailer series is a product designed for the farming sector. They are available in two versions: as a 6-tonne and 8-tonne device. The trailers show outstanding durability. The enclosed spaces of sideboard sections have been secured with a continuous weld. All parts of the shell have been coated with two-component chemically-curing paint, which is characterised by high durability and resistance to UV.


Lightweight, practical

The sideboards of the trailer are additionally equipped with fastening cables. The equipment is characterised by a light, reliable construction made mostly with closed sections. The trailer features a three-way discharge. For safety reasons, the sideboards are centrally locked. The trailers are equipped with a ⌀ 40 mm drawbar eye and a V-type drawbar, as standard. The ⌀ 50 mm eye can be installed for extra charge. The body has a versatile sideboard opening system.


In the area of the rear sideboard, there is a grain discharge outlet, additionally equipped with a lock. The trailer has a rear hydraulic and brake output so you can connect another trailer to it. The trailers can be supplied with numerous facilities and modifications upon customers’ request.

Customised

The sideboards can be painted a different colour to the standard one upon the customers' request.

Technical Specifications

T710/1 T710/2
DMC [kg] 8000 10 200
Load Capacity [kg] 6000 8000
Weight [kg] 2350 2550
Total length / Total width / Total height [mm] 6750 / 2300 / 1650-4000 6750 / 2300 / 1650-4000
Length / Width / Height of cargo space [mm] 4180-4380 / 2080 / 500 4180-4380 / 2080 / 600
Tipper / tipping angle (rear/sides) three-side up to 38o three-side up to 38o
Cargo space height from ground [mm] 1150 1295
Capacity [m3] 4,5 5,3
Volume, including extension [m3] 9,0 9,8

STANDARD EQUIPMENT

  • central system for walls bolting
  • walls bolting line, chute
  • ladder
  • draft pole type V 2000
  • drawbar eye Φ40mm
  • hydraulic & electric installation for second trailer
  • 1-line pneumatic brake with entrance to second trailer
  • tyres 11.5/80.15.3
  • wheel chocks 2 pcs.
  • plastic fenders 4 pcs.

OPTIONAL EQUIPMENT

  • extension (full) 500 mm
  • extension (net) 500 mm
  • tarpaulin with frame
  • working platform with balustrade - extra charge
  • draft pole type V (2000 mm) fi 40 reinforced- extra charge
  • draft pole type V extended (2200 mm) - extra charge
  • draft pole type Y (2100 mm) - extra charge
  • draft pole type Y extended (2350 mm)
  • drawbar eye 50mm for draft pole type Y
  • 2-line pneumatic brake - extra charge
  • hydraulic brakes - extra charge
  • ALB valve - extra charge
  • wheels 12,5/80-15,3 T710/1 - extra charge
  • wheels 400/60-15,5 T710/1 - extra charge
  • wheels 400/60-15,5 T710/2 - extra charge
  • basket for spare wheel with winch
  • spare wheel 11/5/80-15,3
  • spare wheel 12/5/80-15,3
  • spare wheel 400/60-15,5
  • marker lights
  • protection against other vehicles
  • color other than standard - extra charge
