Two-Axle Agricultural Trailer

T711 Tipping trailer

T711 tandem-axle drop-side trailers are versatile machines that will find use on almost every farm. The machine features precise craftsmanship, durability, and a reliable design.

Description
Documents

Your Tool for Flexible Transport

The machine features precise craftsmanship, durability, and a reliable design. The T711 tandem-axle agricultural trailer has extensive standard equipment, making it highly sought after compared to competitors. The trailer has a cargo box with a three-way tipping system.

Chassis

Running Gear

The single-axle chassis used in the T703A trailer ensures excellent maneuverability and ease of handling, making work in the field easier.

Lightweight, solid construction

The T703A trailer features a lightweight yet robust construction that guarantees durability and stability. The lower frame and drawbar are made of high-grade steel, ensuring long service life.

Comfort guaranteed

The support leg with steel wheel allows for stable parking and easy maneuvering of the trailer. This solution enhances user comfort. Additionally, the trailer drawbar is equipped with a simple hitch adapter that enables height adjustment.

Reliable braking systems for complete safety

In the T703A/1 and T713A models, you'll find a single-line pneumatic brake. Optionally, a dual-line pneumatic brake can be installed. The T703A/2 model, on the other hand, is equipped with an overrun brake. It operates automatically – when the tractor brakes, the trailer runs onto it, activating the brakes, allowing for smooth and safe vehicle stopping.

Safety on the road

The rear bumper provides additional protection during transport. It protects against collisions, preventing damage to the trailer. LED lighting ensures low energy consumption, which translates into longer battery life and higher energy efficiency.

Dump body

Efficiency

The ability to carry loads with capacities ranging from 3.8 tons (in T703A/1 and T703A/2 models) to 5 tons (in the T713A model) ensures optimal working conditions for various tasks. The side profiles for the trailers are made of high-grade steel. The sides reinforce the entire structure, ensuring optimal rigidity and excellent sealing during the transport of various loads.

Low loading floor

The floor of the loading box, made of 4 mm thick steel, is located at a height of 980 mm (for T703A/1 and T703A/2 models). This facilitates loading and unloading of materials, minimizing operator effort and saving time.

Central system for walls bolting

The central locking system for the sides at the floor edge in side-board trailers guarantees secure closure of the loading box. The box achieves higher tightness even with very fine loads.

T713A side tipper trailer - side tipping

Functional trailer

Three-way tipping to the left, right, and rear – the T703A offers flexibility in unloading. The side walls and side extensions are single elements – each has a separate set of locks. This allows individual parts to be closed and opened independently and in any order.

Multifunctional

One of the key advantages of the T703A trailer is the ability to dismantle the side walls and posts, allowing the trailer to be converted into a transport platform. This solution enables the transport of bales, loads on box pallets, or Euro pallets. This increases its functionality and wide range of applications on the farm.

Precise unloading

The discharge chute with a gutter in the rear wall facilitates precise and controlled unloading of materials, which increases the efficiency of logistical operations and minimizes unloading losses.

Choose the color that suits you

T710 Model

Box painting

The equipment shown in the photos may vary depending on the selected version.

T711/1

GVW
13,300 kg
Payload
8 t
Capacity
5.45 m3

T711/2

GVW
14,010 kg
Load capacity
10 t
Capacity
6.54 m3

T711/3

GVW
18,000 kg
Payload
12 t
Capacity
6.54 m3

T711/1 - EU

GVW
12,000 kg
Load capacity
8 t
Capacity
5.45 m3

T711/2 - EU

GVW
14,000 kg
Payload
10 t
Capacity
6.54 m3

T711/3 - EU

GVW
16,000 kg
Payload
12 t
Capacity
6.54 m3

Trailer equipment

What comes standard:

  • Side wall 500mm – T711/1
  • Side wall 600mm – T711/2; T711/3
  • Central system for walls bolting
  • Wall bolting chain
  • Chute
  • Ladder
  • Y-type drawbar 2100
  • Hydraulic & electric installation for second trailer
  • Hand parking brake
  • 2-line pneumatic brake with installation to second trailer
  • Tyres 385/65 R22,5 (retreaded)
  • Wheel chocks 2pcs.
  • LED Lights
  • Outline lighting (with EU homologation)
  • Plastic fenders 4 pcs.

Additional equipment:

  • Full extension with gasket 500 mm (for 500 mm bottom side)
  • Extension (net) 350 mm
  • Extension (net) 500 mm
  • Patented system for tightening side walls
  • Spring set for walls bolting
  • Tarpaulin with folding frame (only with PL homologation)
  • Working platform with railing (required when purchasing a tarpaulin)
  • Reinforced V-type drawbar (2000 mm) Ø40
  • Extended V-type drawbar (2200 mm)
  • Y-type drawbar (2100 mm)
  • Extended Y-type drawbar (2350 mm)
  • Hitch eye fi50mm
  • Automatic rear hitch
  • Hydraulic brakes
  • Diaphragm-spring parking brake
  • Automatic braking force regulator, ALB valve – required for EU homologation
  • Wheels 385/65 R22.5 new – required for EU homologation
  • Wheels 400/60-22.5
  • Wheels 445/45 R 19.5 (without homologation)
  • Spare wheel basket
  • Spare wheel new (385/65 R22,5)
  • Spare wheel “retreaded” (385/65 R22,5)
  • Spare wheel 400/60-22.5
  • Protection against other vehicles
  • Extra charge for EU approval
  • Color other than standard

Side height for T711/1 trailer – 500 mm, for T711/2 and T711/3 – 600 mm. Opcjonalnie możesz wyposażyć przyczepę w nadstawkę siatkową lub pełną o różnej wysokości, co znacząco zwiększa jej pojemność, umożliwiając przewóz większych ilości ładunku.

The side seals in the T711 series drop-side trailers provide solid protection for the load against falling out during transport.

Łańcuchy spinające ściany to niezawodne rozwiązanie, które nie tylko pewnie i bezpiecznie zamyka skrzynię ładunkową, ale także usztywnia ściany przestrzeni ładunkowej, co ułatwia transport i chroni Twój ładunek.

Centralny system ryglowania ścian przy krawędzi podłogi w przyczepach burtowych to gwarancja błyskawicznego i pewnego zamykania skrzyni ładunkowej.

T711 series drop-side trailers allow for the transport of loads on Euro pallets, increasing their functionality and flexibility in various transport applications.

W tylnej burcie znajduje się szyber zsypowy z rynną – daje możliwość precyzyjnej regulacji przepływu materiałów, co umożliwia łatwy i efektywny rozładunek zbiorów.

The standard equipment of T711 series drop-side trailers includes hydraulic and electrical systems for a second trailer, ensuring convenience and readiness to transport additional load, which means greater efficiency and time savings in your agricultural operations.

LED lighting – ensures low energy
consumption, which translates into longer battery life and higher energy efficiency.

W tylnej burcie znajduje się szyber zsypowy z rynną – daje możliwość precyzyjnej regulacji przepływu materiałów, co umożliwia łatwy i efektywny rozładunek zbiorów.

Efficiency on every hectare

We deliver valuable and functional solutions that meet your specific needs and help you achieve better results in the field.
